Schwille IsarAIR ppm: CO2 ventilation control with room sensor
The Schwille IsarAIR ppm (100-680) is a CO2 ventilation control for offices, seminar rooms and classrooms. A room sensor continuously monitors the CO2 content of the room air. When a manually adjustable limit is exceeded, the control switches the fans on.
The universal ventilation control 100-660 with indoor and outdoor sensor is integrated. In combination with fans with heat recovery, ventilation can be designed to save energy.
Technical data
| Property | Value |
| Operating voltage | 230 V / 50 Hz / 2.5 W |
| Fan current | max. 5 A, 230 V |
| Fan connection | fan terminals |
| Operation and display | 5-inch touchscreen |
| Resolution | 0.1 degrees |
| Measuring range temperature | -26 °C to +76 °C |
| Measuring range humidity | 5% to 99% |
| Measuring range dew point | -54 °C to +75 °C |
| Accuracy temperature | ± 0.5% |
| Accuracy humidity / dew point | ± 1.8% |
| Measuring range CO2 | 400 to 2000 ppm |
| Accuracy CO2 | ± 3% of reading |
| Adjustable switching point CO2 | 400 to 2000 ppm (factory setting 800 ppm) |
| Switching hysteresis | ± 30 digits |
| CO2 sensor | can be placed up to 30 m away |
| Sensor cable length | 10 m each, special length max. 50 m per sensor |
| Wall housing dimensions | 165 x 155 x 70 mm |
| Operating temperature control | -20 °C to 50 °C |
| Mounting | wall mounting |
| Data logging | hourly to microSD/SDHC card up to 4 GB (not included), CSV file |
Areas of use
- Offices and meeting rooms
- Seminar rooms
- Classrooms
The CO2 limit above which ventilation starts can be set manually. The control does not replace a ventilation concept for the room.
Scope of delivery
- CO2 ventilation control
- Room sensor
- Indoor and outdoor sensor
Manufacturer: Schwille Elektronik Produktions- und Vertriebs GmbH. Technical data according to manufacturer information.
- WEEE-Reg.-Nr. DE
- DE 865 409 15
- Display
- 5-inch touchscreen
- Manufacturer
- Schwille
- Power
- 2.5 watts
- Weight
- 1.1 kg
- Voltage
- 230 V / 50 Hz
- Measuring range
- temperature -26 to +76 °C, humidity 5 - 99%, dew point -54 to +75 °C, CO2 400 - 2000 ppm
- Working range
- -20 to 50°C
- Dimensions
- 165 x 155 x 70 mm
- Shipping Weight
- 2.1 kg
