Efficient Air Circulation with the ER ECO 30 M
The ER ECO 30 M axial duct fan from CasaFan is an excellent choice for those seeking a powerful and energy-efficient solution for ventilation. This duct fan is specifically designed for commercial use and is ideal for duct or channel systems with low to medium resistance. With a nominal diameter of 300 mm, it offers an optimal air output of up to 2200 m³/h, making it a great choice for larger applications.
The fan features a brushless EC motor, which not only saves energy but also ensures low noise levels. The robust housing made of galvanized steel and high-quality materials ensure durability and reliability. Additionally, the ER ECO 30 M is equipped with a potentiometer for control, allowing for flexible speed adjustments.
Compared to its counterpart, the ER ECO 25 M axial duct fan, which has a nominal diameter of 250 mm, the ER ECO 30 M offers increased air output and is therefore better suited for larger spaces or applications with higher air circulation demands.
- Energy-efficient: The brushless EC motor significantly reduces power consumption.
- Low noise: With a sound pressure level of only 51 db(A), the fan ensures a quiet environment.
- Versatile use: Optimal for commercial applications and duct systems.
- Easy control: Thanks to the integrated potentiometer, the speed can be flexibly adjusted.
- Robust construction: The galvanized steel housing provides high corrosion protection.
The different variants of the ER ECO series mainly differ in nominal diameter and thus in air output. The ER ECO 30 M is ideal if you need a powerful solution for larger applications. The decision for this variant depends on the specific requirements of your project, especially regarding the required air output and the available space in the duct system.
| Device names | ER ECO 30 M |
| Manufacturer | CasaFan |
| Material | Steel galvanized |
| Color | Black, two-layer anti-corrosion paint |
| Special feature | energy saving |
| Weight | 4,5 kg |
| Nominal size | 300 mm |
| Supply voltage | 230 volt ~ 50 Hz |
| Degree of protection | IP54 |
| Rated current | 0.5 amps |
| Protection class | I |
| Maximum power consumption | 70 watts |
| Maximum RPM | 1500 U/min |
| Maximum Air Flow | 2200 m³/h |
| Total pressure Pmax | 150 PA |
| Sound pressure level Lp - 2m | 49 db(A) |
| Maximum temperature | +60 °C |
| Generators | single phase |
| Engine | 0-10 volts interface, single-phase, insulation class B, external rotor motor with ball bearings |
| Fan Type | Axial fan, duct fan |
| Picture | Artikcle | Nominal size | Max. Power Consumption | Max. RPM | Max. Air performance | Item No. | Price |
|---|---|---|---|---|---|---|---|
 |
ER ECO 25 M axial duct fan | 250 mm | 50 watts | 2400 U/min | 1600 m³/h | 973460 | 799,99 € Preis inkl. 19 % MwSt. zzgl. Versandkosten |
|
ER ECO 30 M axial duct fan | 300 mm | 70 watts | 1500 U/min | 2200 m³/h | 973462 | 849,99 € Preis inkl. 19 % MwSt. zzgl. Versandkosten |
|
ER ECO 35 M axial duct fan | 350 mm | 75 watts | 1250 U/min | 3000 m³/h | 973464 | 849,99 € Preis inkl. 19 % MwSt. zzgl. Versandkosten |
|
ER ECO 40 M axial duct fan | 400 mm | 140 watts | 1100 U/min | 4100 m³/h | 973466 | 1199,99 € Preis inkl. 19 % MwSt. zzgl. Versandkosten |
|
ECO 45 M axial duct fan | 450 mm | 350 watts | 1300 U/min | 6500 m³/h | 973468 | 1449,99 € Preis inkl. 19 % MwSt. zzgl. Versandkosten |
|
ER ECO 50 M axial duct fan | 500 mm | 360 watts | 1100 U/min | 7350 m³/h | 973470 | 1649,99 € Preis inkl. 19 % MwSt. zzgl. Versandkosten |
|
ER ECO 60 M axial duct fan | 600 mm | 240 watts | 800 U/min | 9000 m³/h | 973472 | 1749,99 € Preis inkl. 19 % MwSt. zzgl. Versandkosten |
