Efficient Ventilation with the CA 315 MD SE RF Roof Fan
The CA 315 MD SE RF roof pipe centrifugal fan is the ideal solution for those seeking a powerful and reliable roof fan. With its modern design and the use of high-quality materials, this fan not only impresses with its efficiency but also with its durability. It is excellently suited for industrial applications where effective air circulation is required, as well as for use in commercial spaces.
A standout feature of the CA 315 MD SE RF is its easy installation, which can be carried out effortlessly thanks to the user-friendly design and accessible junction boxes. The three-speed settings allow for adjustment of the air performance to meet specific requirements. Additionally, the ball-bearing motor with thermal overload protection ensures long service life and quiet operation.
Compared to other variants such as the CA 100 MD E RF roof pipe centrifugal fan, the CA 315 MD SE RF offers a larger nominal diameter of 315 mm, making it particularly suitable for larger spaces and applications. The similarities between the models lie in their robust construction and efficiency, while the differences mainly consist of nominal diameter and power output.
- Nominal Diameter: The CA 315 MD SE RF has a nominal diameter of 315 mm, making it ideal for larger applications.
- Speed Control: The fan offers stepless control, allowing for precise adjustment of air performance.
- Material Quality: Made of high-quality phosphated steel sheet, providing high resistance to environmental influences.
- Noise Level: With a sound pressure level of only 37.5 dB(A), the fan operates particularly quietly.
- Areas of Application: Ideal for industrial applications as well as for commercial spaces where high air performance is required.
In summary, the CA 315 MD SE RF roof pipe centrifugal fan is an excellent choice for anyone who values efficiency and durability. Its easy installation and high air performance make it an indispensable device in any commercial environment.
| Nominal Diameter | 315 mm |
| Electrical Voltage | 220-240 Volts |
| Electrical Power | 50 Watts |
| Speed | 2405 RPM |
| Number of Stages | 3 Stages |
| Air Performance | 265 m³/h |
| Total Pressure Pmax | 389.3 Pa |
| Color | Hammered Gray Coated |
| Material | Roof Cap Plastic, Galvanized Steel Sheet |
| Motor | speed adjustable, ball bearing, thermal overload protection |
| Sound Pressure | 37.5 dB(A) |
| Protection Class | IP 45 |
| Protection Category | II |
| Max Temperature | 50 °C |
| Fan Type | Roof Fan, Centrifugal Fan, Pipe Fan |
