Axial fan CasaFan EQ 40/4 T - 400V-50/60Hz

Axial Fan CasaFan EQ 40/4 T - The Powerful Variant for Your Project

The Axial Fan CasaFan EQ 40/4 T - 400V-50/60Hz is the ideal solution for efficient wall ventilation in commercial and industrial applications. With an airflow of up to 4400 m³/h and an energy consumption of only 195 watts, this fan offers an excellent combination of performance and energy efficiency. It is well-suited for use in offices, workshops, restaurants, discotheques, and other spaces requiring reliable air circulation.

The EQ series from CasaFan includes various models that differ in their construction and performance. The Axial Fan CasaFan EQ 40/4 T differs from the main variant, the Axial Fan CasaFan EQ 20/4 T - 400V-50/60Hz, by its larger airflow and higher power consumption. This variant is ideal for applications where strong air circulation is required.

Advantages of the Axial Fan CasaFan EQ 40/4 T include:

• High airflow: 4400 m³/h for effective ventilation
• Energy efficient: Only 195 watts of power consumption
• Robust construction: Casing made of powder-coated, galvanized steel
• Versatile application: Suitable for various uses in commercial and industrial settings

In addition to its advantages, the Axial Fan CasaFan EQ 40/4 T offers easy installation and maintenance. Thanks to its ball-bearing external motor and reversible function, it can be flexibly installed in different positions. With a temperature resistance of -25°C to +55°C, it is ideal for a variety of environments.

Here are the key similarities and differences between the variants:

• Common features: All models in the EQ series are reversible, have low noise levels, and are suitable for continuous operation.
• Differences: Airflow and power consumption vary by model. The EQ 40/4 T offers the highest airflow in the series.
