Axial fan CasaFan EQ 20/4 T - 400V-50/60Hz

Built-in wall fan CasaFan EQ 20/4 T - 400V/~50/60Hz

Use for commercial and industrial ventilation such as:

✓ Cellar rooms	✓ Laundries
✓ Workshops	✓ Restaurants
✓ Baths	✓ Theatres
✓ Offices	✓ Bars
✓ Laboratories	✓ Discoteques
✓ Factories	✓ Installation in machines
✓ Salesrooms	✓ etc.

The axial wall fan from Casafan is available in 13 versions from 200 mm - 600 mm. Its casing, as well as its profiled, aerodynamic and optimised blades of nominal size 20, 25, 30 and 40 are made of powder-coated galvanised sheet steel in black. The nominal sizes 35, 50 and 60 are made of black plastic.
The EQ series has low specific consumption values and a low noise level at best performance. Furthermore, all models except EQ 20/4 M and EQ 25/4 M are reversible.
The wall-mounted fans are suitable for installation in any position due to their ball-bearing mounted external motor with maximum efficiency.
Wide frequency motor 50/60 Hz, insulation class F.
The motor is automatically switched off by integrated thermal contacts when overheating and automatically switched on again when cooling down.
The speed is adjustable by means of a speed regulator or step transformer. For sizes 50 and 60 PTC thermistors on terminal board for connecting a motor protection device.
